GRX®

for extremely ­corrosive media in connection with low pressures + high ­temperatures.

REMBE® graphite rupture disc GRX®
Reliable. German. Safety.

REMBE® GRX®: The first rupture disc with FDA conformity.

REMBE® graphite rupture discs offer you the familiar REMBE® quality and reliability – even in extremely corrosive media, low pressures and high temperatures. Like all REMBE® rupture discs, the graphite rupture discs are also manufactured in Germany. The maximum working pressure is 80 %* of the minimum burst pressure. REMBE® graphite rupture discs are applicable for highest temperatures by using a unique chemical vapour deposition method (PyC coating). The rupture discs are applicable from -180 °C up to +500 °C under oxidizing and reducing atmosphere, +1,500 °C under inert conditions. Versions with vacuum and back pressure support are also suitable for the above mentioned operating conditions.
* Depending on the specific application.
Depending on the application and nominal pipe size, the rupture discs are installed directly between flanges. If required, you will also receive a suitable signalling device which, in conjunction with your process control system, will inform you about the rupture disc's response. Nominal pipe size available from DN 15 (0.5") to DN 600 (24") with burst pressures from 20 mbarg (~0.3 psig) to 63 barg (~900 psig).
REMBE® graphite rupture disc GRX® with Accessoires

signalling devices

Automated processes use intelligent signalling systems to keep you informed at all times about the status of your entire plant and any faults that may arise. You can even install signalling devices for rupture discs that have already been installed.
Advantages
  • Product purity (carbon content ≥ 99,9 % for PyC coating).
  • Highest temperature resistance (+1,500 °C under inert conditions) and leak-tightness due to an innovative coating.
  • FDA-conformity**.
  • Highest corrosion resistance.
  • Extra long service life.
  • Temperature-independent material properties and burst pressures.
  • Reusable vacuum support.
  • Manufacturing without polymer sealant.
  • Simple installation.
** Excluded processes with infant food and breast milk.
More types
GRX® UK
Graphite Rupture Disc
Inverted version for low and medium pressures.
GRX® UKV
Graphite Rupture Disc
Inverted version with vacuum support.
GRX® MT
Graphite Rupture Disc
Mono type for medium and high pressures.
Technical data
Product parameters
FeatureCharacteristicsVariations
Signalling available
SB(-S), SGK, SBK-S
Safety valve isolation
(✓)
-
Temperature range | °C
-180 °C up to about +500 °C
-
Applications
  • autoclaves
  • chemical industry
  • chemical reactors
  • condensers
  • cryostats + transport containers
  • gas compressor modules
  • gas turbines for power generation
  • intermodal containers for corrosive / aggressive media
  • oil and gas separation and treatment
  • petrochemical plants
  • power plants
  • process vessels
  • reactors
  • refineries
  • silo
  • separators
  • water injection pumps
Industries
  • brewery
  • chemical- petrochemical
  • food
  • hydrogen
  • oil and gas industry
  • pharmaceutical industry
Click and drag image to view.

Scan the QR code with your iOS camera* to see an AR preview of the product.
ERO AR Viewer Ru
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
