threaded holder

for small assemblies.

REMBE® threaded holder
Reliable. German. Safety.
REMBE® threaded holders are particularly suitable for pressure safeguarding of small-scale systems, e. g. pressure systems in laboratories, autoclaves, small pressure vessels, etc. The holders are made in ss304, ss303 or ss316Ti. Depending on the process medium other alloys, e. g. Nickel, Monel, Titan, Hastelloy, are available. Standard connection threads are NPT or G. The threaded holders are suited to accommodation of conventional domed rupture discs as well as for triple-section rupture discs.
Due to the construction of the threaded holders the tag plate of the disc is separately supplied. The tag plate must visible be fixed at the fitting. The U-type screw-in holder is used to save space, especially in rigid pipe systems.
REMBE® threated holder types

U-Type

Screw-in holder with union nut
for rigid pipe systems.

AG AS AM

Screw-in holder for small assemblies
Small assemblies such as B. autoclaves, small pressure vessels or wind turbines are protected with bursting discs in small nominal sizes. The bursting disc holders AG, AM and AS can be equipped with a wide variety of connections for these applications, depending on requirements. The included bursting discs can also be replaced quickly and easily.

AG AS AM

Screw-in holder for small assemblies
Small assemblies such as B. autoclaves, small pressure vessels or wind turbines are protected with bursting discs in small nominal sizes. The bursting disc holders AG, AM and AS can be equipped with a wide variety of connections for these applications, depending on requirements. The included bursting discs can also be replaced quickly and easily.

AG AS AM

Screw-in holder for small assemblies
Small assemblies such as B. autoclaves, small pressure vessels or wind turbines are protected with bursting discs in small nominal sizes. The bursting disc holders AG, AM and AS can be equipped with a wide variety of connections for these applications, depending on requirements. The included bursting discs can also be replaced quickly and easily.
Advantages
  • Standard threads and specific threads on customer request (100% customized).
  • easy replacement of bursting disc and bursting disc holder.
  • High tightness and low leakage through adapted and appropriately designed sealing surfaces.
  • Reduced costs through exchangeable bursting discs with equally high tightness.
More types
AG, AS, AM
Small assemblies such as B. autoclaves, small pressure vessels or wind turbines are protected with bursting discs in small nominal sizes. The bursting disc holders AG, AM and AS can be equipped with a wide variety of connections for these applications, depending on requirements. The included bursting discs can also be replaced quickly and easily.
U-Type
The rupture disc holder is used to save space, especially in rigid pipe systems.
Technical data
Type ½-200 (1/2") suitable for up to max. 200 bar (2,900 psi)
Type Connections
Inlet 		Connections
Outlet 		Wrench size, mm
Inlet 		Wrench size, mm
Outlet 		Length of unit
mm
½-200 AG ¼" or ½" ¼" or ½" 30 32 ~ 80
½-200 AM ¼" or ½" free 30 32 ~ 50
½-200 AS ¼" or ½" muffled 30 32 ~ 65
Different sizes, pressure classes, temperatures, materials and fittings available on request.
Type ½-600 (1/2") suitable for up to max. 600 bar (8,700 psi)
Type Connections
Inlet 		Connections
Outlet 		Wrench size, mm
Inlet 		Wrench size, mm
Outlet 		Length of unit
mm
½-600 AG ¼" or ½" ¼" or ½" 30 32 ~ 75
½-600 AM ¼" or ½" centered 30 32 ~ 55
½-600 AS ¼" or ½" muffled 30 32 ~ 60
Different sizes, pressure classes, temperatures, materials and fittings available on request.
Type ¾ 200 (3/4") suitable for up to max. 200 bar (2,900 psi)
Type Connections
Inlet 		Connections
Outlet 		Wrench size, mm
Inlet 		Wrench size, mm
Outlet 		Length of unit
mm
¾-200 AG ¼" or ¾" ¼" or ¾" 46 41 ~ 125
¾-200 AM ¼" or ¾" free 46 41 ~ 80
½-600 AS ¼" or ½" muffled 46 41 ~ 85
Different sizes, pressure classes, temperatures, materials and fittings available on request.
Type 1-100 (1") suitable for up to max. 100 bar (1,450 psi)
Type Connections
Inlet 		Connections
Outlet 		Wrench size, mm
Inlet 		Wrench size, mm
Outlet 		Length of unit
mm
1-100 AG ¼" or 1" ¼" or 1" 55 5 ~ 125
1-100 AM ¼" or 1" free 55 55 ~ 120
1-100 AS ¼" or 1" muffled 55 55 ~ 95
Different sizes, pressure classes, temperatures, materials and fittings available on request.
Applications
  • autoclaves
  • chemical industry
  • chemical reactors
  • cryogenic applications
  • cryostats + transport containers
  • desalination plants
  • food production
  • gas compressor modules
  • gas-tight pressure vessels
  • heat exchangers
  • isolation of safety valves
  • LDPE (thermoplastic)
  • LNG
  • mixers
  • oil and gas separation and treatment
  • petrochemical plants
  • power plants
  • process vessels
  • reactors
  • refineries
  • reverse osmosis systems
  • separators
  • water injection pumps
Industries
  • brewery
  • chemical- petrochemical
  • food
  • oil and gas industry
Downloads

Due to the special design of the various REMBE® rupture disc holders, incorrect installation of the associated rupture disc is impossible.

Click and drag image to view.

Scan the QR code with your iOS camera* to see an AR preview of the product.
Einschraubhalter AR Viewer Ru
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
